Components
Rear Door Window Glass Replacement
(4Door, 5Door)
1.
Pull down rear door window glass by pressing the power window
glass switch.
2.
Remove the rear door trim.
...
Cruise Control Switch Component Location
1. Remote control switch(LH)
2. Remote control switch(RH)
3. Bluetooth hands free switch
4. Trip switch
...
ECM Terminal And Input/Output signal (A/T)
ECM Terminal Function
Connector [CNG-AA]
Pin No.
Description
Connected to
1
Ignition Coil (Cylinder #2) control output
Ignition Co ...
